Three Roller Mill

Description

Model Number:Zoway-SG
1. Compliance:CE Certified
2. Warranty:2 Year limited warranty with lifetime support
3. Delivery Time:In Stock

Email: imani@batterypackassembly.com
Tel:+86 13174506016
WhatsApp:+86 13174506016
WeChat:+86 18659217588

Content

Email: imani@batterypackassembly.com

Overview

Three roller mill is welded by high quality steel plate. The transmission gear adapts oil-immersed type and the operative hand-wheel is transmitted by gear. It features beautiful appearance, convenient to operate, long life and so on. Particularly it is suitable for grinding the material with high dispersive viscosity and fine size.

Character

SG series is a new generation product on basic of traditional type,

●Chain gears driving, oil tank gear box, fewer noise, longer life time.

●Hydraulic piston driving, pressure guage.

● SUS304 stainless steel discharge hopper.

Parameter

Model		*SG6/S150**	*SG9/S260**	*SG16/SM450**	*SG16L/SM450L**
Roller diameter（mm）		150	260	405	405
Length of roller working surface（mm）		300	675	810	1000
Distance from discharge hole to ground （mm）		660	580/530	780/700	780/700
Output（L/h）		25~40	60~80	120~150	130~200
Roll rotating speed（r/min）	Low speed roll	34	23	14	14
	Medium speed roll	78	64	43	43
	High speed roll	181	183	130	130
Main motor power（KW）		2.2~3	7.5	15-18.5	22
Overrall dimension LWH（mm）		9208801150	169013301300	215017951600	235017501600
Machine weight（kg）		500	2000	5300	5800
Packing dimension LWH（mm）		100010001400	180014501600	225018501950	245018502000
